| Broj dijela | LQ070T5DR01 |
| Marka | SHARP |
| Veličina | 7.0 |
| Primjena | CNS |
| Rezolucija | 480×240 |
| Sastav | LCM |
| Svjetlina | 400 |
| CR | 100:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | TTL |
| marka panela | SHARP |
| panelni model | LQ070T5DR01 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 7.0 inch |
| rezolucija | 480(RGB)×240 , WQVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 154.08×87 mm |
| obris | 170.1×103.4 mm |
| površinski | Antiglare, Antireflection |
| svjetlina | 400 cd/m² (Typ.) |
| omjer kontrasta | 100:1 (Min.) |
| boje prikaza | 262K (6-bit) |
| vrijeme odziva | 30/50 (Typ.)(Tr/Td) |
| kut gledanja | 65/65/40/65 (Typ.)(CR≥5)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 2 pcsCCFLWithout Driver |
| signalno sučelje | Parallel RGB (1 ch, 6-bit), 36 pins |
| ulazni napon | 5/10/-10V (Typ.)(VSH/VGH/VGL) |
| primjena | CNS |
