| Broj dijela | LQ070Y3DG01 |
| Marka | SHARP |
| Veličina | 7.0 |
| Primjena | DPF |
| Rezolucija | 800×480 |
| Sastav | LCM |
| Svjetlina | 380 |
| CR | 350:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | TTL |
| marka panela | SHARP |
| panelni model | LQ070Y3DG01 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 7.0 inch |
| rezolucija | 800(RGB)×480 , WVGA |
| način prikaza | Transmissive |
| aktivno područje | 152.4×91.44 mm |
| obris | 175×111.5×13.8 mm |
| površinski | |
| svjetlina | 380 cd/m² (Typ.) |
| omjer kontrasta | 350:1 (Typ.) |
| boje prikaza | 262K (6-bit) |
| vrijeme odziva | 10/15 (Typ.)(Tr/Td) |
| kut gledanja | 60/60/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 1 pcsCCFLWithout Driver |
| signalno sučelje | CMOS (1 ch, 6-bit), 32 pins |
| ulazni napon | 5.0V (Typ.) |
| primjena | DPF |
