| Broj dijela | LQ070Y5DG20 |
| Marka | SHARP |
| Veličina | 7.0 |
| Primjena | CNS |
| Rezolucija | 800×480 |
| Sastav | LCM |
| Svjetlina | 500 |
| CR | 100:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | TTL |
| marka panela | SHARP |
| panelni model | LQ070Y5DG20 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 7.0 inch |
| rezolucija | 800(RGB)×480 , WVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 156×82.8 mm |
| obris | 167×93×7.5 mm |
| površinski | Antiglare |
| svjetlina | 500 cd/m² (Typ.) |
| omjer kontrasta | 100:1 (Min.) |
| boje prikaza | 262K (6-bit) |
| vrijeme odziva | 30/50 (Typ.)(Tr/Td) |
| kut gledanja | 65/65/65/60 (Typ.)(CR≥5)(L/R/U/D) |
| tip svjetiljke | 1 pcsCCFLWithout Driver |
| signalno sučelje | Parallel RGB (1 ch, 6-bit), 50 pins |
| ulazni napon | 5.3/3.3/15/-12V (Typ.)(VSHA/VSHD/VDD/VEE) |
| primjena | CNS |
| LQ070M1SX01 | SHARP | 7.0 | 1200×1920 |
| LQ070S1DW01 | SHARP | 7.0 | 600×800 |
| LQ070T1LG01 | SHARP | 7.0 | 800×480 |
| LQ070T3AG02 | SHARP | 7.0 | 480×234 |
| LQ070T5AR01 | SHARP | 7.0 | 480×234 |
| LQ070T5DR06 | SHARP | 7.0 | 480×240 |
| LQ070Y3DG3A | SHARP | 7.0 | 800×480 |
| LQ070Y3LW01 | SHARP | 7.0 | 800×480 |
| LQ070Y5DG01 | SHARP | 7.0 | 800×480 |
| LQ070Y5DG12 | SHARP | 7.0 | 800×480 |
| CLAA061LA0DCW | CPT | 6.1 | 800×480 |
| CLAA069LA0ACW | CPT | 7.0 | 800×480 |
| DD070NA-02A | Innolux | 7.0 | 800×480 |
| LQ050Q5DR01 | SHARP | 5.0 | 320×240 |
| LQ058T5DG31 | SHARP | 5.8 | 480×240 |
| LQ080Y5DZ30A | SHARP | 8.0 | 800×480 |
| PD050VX6 | E Ink | 5.0 | 640×480 |
| PW070XUA | E Ink | 7.0 | 480×234 |
| TM062RDZG10 | Tianma | 6.2 | 800×480 |
| TM101DDHG01 | Tianma | 10.1 | 1024×600 |
