| Broj dijela | LA050WQ1-TD01 |
| Marka | LG Display |
| Veličina | 5.0 |
| Primjena | CNS |
| Rezolucija | 480×272 |
| Sastav | LCM |
| Svjetlina | 1100 |
| CR | 500:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | LG Display |
| panelni model | LA050WQ1-TD01 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 5.0 inch |
| rezolucija | 480(RGB)×272 , WQVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 110.88×62.478 mm |
| obris | 124×75.2×8.3 mm |
| površinski | Antiglare, Hard coating (3H) |
| svjetlina | 1100 cd/m² (Typ.) |
| omjer kontrasta | 500:1 (Typ.) |
| boje prikaza | 262K (6-bit), CIE193175% |
| vrijeme odziva | 6/9 (Typ.)(Tr/Td) |
| kut gledanja | 55/55/55/25 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 5S2PWLEDWithout Driver |
| signalno sučelje | Parallel RGB (1 ch, 6-bit), 60 pins |
| ulazni napon | 3.3/10.0V (Typ.)(DVDD/AVDD) |
| primjena | CNS |
