| Broj dijela | YXD090TN02-40NM01 |
| Marka | SEBO |
| Veličina | 9.0 |
| Primjena | PAD |
| Rezolucija | 1280×800 |
| Sastav | LCM |
| Svjetlina | 250 |
| CR | 700:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | SEBO |
| panelni model | YXD090TN02-40NM01 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 9.0 inch |
| rezolucija | 1280(RGB)×800 , WXGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 193.92×121.2 mm |
| obris | 206.76×135.06×3.9 mm |
| površinski | Hard coating |
| svjetlina | 250 cd/m² (Typ.) |
| omjer kontrasta | 700:1 (Typ.) |
| boje prikaza | 16.7M (8-bit) |
| vrijeme odziva | 10/15 (Typ.)(Tr/Td) |
| kut gledanja | 70/70/70/50 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | WLEDWithout Driver |
| signalno sučelje | LVDS (1 ch, 8-bit), 40 pins |
| ulazni napon | 3.3/11/20/-6.8V (Typ.)(DVDD/AVDD/VGH/VGL) |
| primjena | PAD |
| AT090TN23 | Innolux | 9.0 | 1280×800 |
| CLAA090NA02CW | CPT | 9.0 | 1024×600 |
| CLAA090NA06CW | CPT | 9.0 | 1024×600 |
| LQ090Y3DG01A | SHARP | 9.0 | 800×480 |
| LTA090B230F | TOSHIBA | 9.0 | 536×328 |
| LTL090CL01-002 | Samsung | 9.0 | 1920×1280 |
| T-55561D090J-LW-A-AAN | Kyocera | 9.0 | 800×480 |
| TM090JDH01 | Tianma | 9.0 | 1280×800 |
| TX23D86VM0BAA | KOE | 9.0 | 1280×768 |
| YXD090TN02-40NM01 | SEBO | 9.0 | 1280×800 |
| B101EAN01.2 | AUO | 10.1 | 1280×800 |
| BP070WS1-400 | BOE | 7.0 | 1024×600 |
| BP101WX1-200 | BOE | 10.1 | 1280×800 |
| CLAA070WP03XG | CPT | 7.0 | 800×1280 |
| HSD100PXN1-A00-C40 | HannStar | 10.0 | 1024×768 |
| LP101WH4-SLA6 | LG Display | 10.1 | 1366×768 |
| LTL089CL02-002 | Samsung | 8.9 | 1920×1200 |
| LTN070NL01 | Samsung | 7.0 | 1024×600 |
| TM090JDH01 | Tianma | 9.0 | 1280×800 |
| TV101WUM-NH0 | BOE | 10.1 | 1200×1920 |
