| Broj dijela | T-55561D090J-LW-A-AAN |
| Marka | Kyocera |
| Veličina | 9.0 |
| Primjena | IA |
| Rezolucija | 800×480 |
| Sastav | LCM |
| Svjetlina | 400 |
| CR | 900:1 |
| Boje | 262K/16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | OPTREX |
| panelni model | T-55561D090J-LW-A-AAN 1 Compatible model |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 9.0 inch |
| rezolucija | 800(RGB)×480 , WVGA |
| način prikaza | IPS, Normally Black, Transmissive |
| aktivno područje | 196.8×118.08 mm |
| obris | 219×136.2 mm |
| površinski | Antiglare, Hard coating (3H) |
| svjetlina | 400 cd/m² (Typ.) |
| omjer kontrasta | 900:1 (Typ.) |
| boje prikaza | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193172% |
| vrijeme odziva | 12/12 (Typ.)(Tr/Td) |
| kut gledanja | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 7S2PWLEDWithout Driver |
| signalno sučelje | LVDS (1 ch, 6/8-bit), 20 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | IA |
