| Broj dijela | CLAA070WP03XG |
| Marka | CPT |
| Veličina | 7.0 |
| Primjena | PAD |
| Rezolucija | 800×1280 |
| Sastav | LCM |
| Svjetlina | 450 |
| CR | 700:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | CPT |
| panelni model | CLAA070WP03XG |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 7.0 inch |
| rezolucija | 800(RGB)×1280 , WXGA |
| način prikaza | HFFS, Normally Black, Transmissive |
| aktivno područje | 94.2×150.72 mm |
| obris | 104.32×161.67×4.05 mm |
| površinski | Glare (Haze 0%), Hard coating (3H) |
| svjetlina | 450 cd/m² (Typ.) |
| omjer kontrasta | 700:1 (Typ.) |
| boje prikaza | 262K (6-bit), CIE193160% |
| vrijeme odziva | 30 (Typ.)(Tr+Td) |
| kut gledanja | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | WLEDEmbedded (LED Driver) |
| signalno sučelje | LVDS (1 ch, 6-bit), 31 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | PAD |
