| Broj dijela | CLAA070WA01 |
| Marka | CPT |
| Veličina | 7.0 |
| Primjena | VDP |
| Rezolucija | 480×234 |
| Sastav | LCM |
| Svjetlina | 500 |
| CR | 300:1 |
| Boje | Full color |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | Analog |
| marka panela | CPT |
| panelni model | CLAA070WA01 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 7.0 inch |
| rezolucija | 480(RGB)×234 |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 154.08×86.58 mm |
| obris | 164.9×100 mm |
| površinski | Antiglare |
| svjetlina | 500 cd/m² (Typ.) |
| omjer kontrasta | 300:1 (Typ.) |
| boje prikaza | Full color |
| vrijeme odziva | 30 (Typ.)(Tr+Td) |
| kut gledanja | 60/60/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 1 pcsCCFLWithout Driver |
| signalno sučelje | TFT Specific Analog RGB, 26 pins |
| ulazni napon | 5/5/15/-10V (Typ.)(VCC/AVDD/VGH/VGL) |
| primjena | VDP |
