| Broj dijela | CLAA070LF05CW |
| Marka | CPT |
| Veličina | 7.0 |
| Primjena | CNS |
| Rezolucija | 800×480 |
| Sastav | LCM |
| Svjetlina | 300 |
| CR | 400:1 |
| Boje | 16.2M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | CPT |
| panelni model | CLAA070LF05CW |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 7.0 inch |
| rezolucija | 800(RGB)×480 , WVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 154.08×85.92 mm |
| obris | 164.9×100×3.7 mm |
| površinski | Antiglare |
| svjetlina | 300 cd/m² (Typ.) |
| omjer kontrasta | 400:1 (Typ.) |
| boje prikaza | 16.2M (6-bit + FRC), CIE193150% |
| vrijeme odziva | 25 (Typ.)(Tr+Td) |
| kut gledanja | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 3S6PWLEDWithout Driver |
| signalno sučelje | TTL (1 ch, 8-bit), 50 pins |
| ulazni napon | 3.3/9.6/18.0/-6 (Typ.)(DVDD/AVDD/VGH/VGL) |
| primjena | CNS |
| CLAA070LC0ACW | CPT | 7.0 | 800×480 |
| CLAA070MA32BW | CPT | 7.0 | 800×600 |
| CLAA070ND02 | CPT | 7.0 | 1024×600 |
| CLAA070ND22CW | CPT | 7.0 | 1024×600 |
| CLAA070ND23CW | CPT | 7.0 | 1024×600 |
| CLAA070ND36CW | CPT | 7.0 | 1024×600 |
| CLAA070VA01 | CPT | 7.0 | 800×480 |
| CLAA070WA01 | CPT | 7.0 | 480×234 |
| CLAA070WP03 | CPT | 7.0 | 800×1280 |
| CLAA070WP03XG | CPT | 7.0 | 800×1280 |
| CLAA070NJ01CW | CPT | 7.0 | 1024×600 |
| CLAA102NA0DCW | CPT | 10.2 | 1024×600 |
| LA070WV4-SD01 | LG Display | 7.0 | 800×480 |
| LA070WV5-SL01 | LG Display | 7.0 | 800×480 |
| LB070WQ6-TD01 | LG Display | 7.0 | 400×234 |
| LQ035Q5DG01 | SHARP | 3.5 | 320×240 |
| LQ038Q5DR01 | SHARP | 3.8 | 320×240 |
| LQ058T5BA01 | SHARP | 5.8 | |
| LS080HT111 | Innolux | 8.0 | 800×600 |
| M101GWT9 R3 | IVO | 10.1 | 1024×600 |
