| Broj dijela | LTM170EU-A01 |
| Marka | Samsung |
| Veličina | 17.0 |
| Primjena | DMPC |
| Rezolucija | 1280×1024 |
| Sastav | LCM |
| Svjetlina | 270 |
| CR | 400:1 |
| Boje | 16.2M |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | Analog |
| marka panela | SAMSUNG |
| panelni model | LTM170EU-A01 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 17.0 inch |
| rezolucija | 1280(RGB)×1024 , SXGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 337.92×270.336 mm |
| obris | 358.5×296.5×25.4 mm |
| površinski | Antiglare (Haze 25%), Hard coating (3H) |
| svjetlina | 270 cd/m² (Typ.) |
| omjer kontrasta | 400:1 (Typ.) |
| boje prikaza | 16.2M (6-bit + FRC), CIE193165% |
| vrijeme odziva | 5/20 (Typ.)(Tr/Td) |
| kut gledanja | 60/60/50/50 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 4 pcsCCFLEmbedded (Inverter) |
| signalno sučelje | Analog RGB, 27 pins |
| ulazni napon | 12.0V (Typ.) |
| primjena | DMPC |
