| Broj dijela | LTM170EU-L31 |
| Marka | Samsung |
| Veličina | 17.0 |
| Primjena | DMPC |
| Rezolucija | 1280×1024 |
| Sastav | LCM |
| Svjetlina | 300 |
| CR | 1000:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | LVDS |
| marka panela | SAMSUNG |
| panelni model | LTM170EU-L31 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 17.0 inch |
| rezolucija | 1280(RGB)×1024 , SXGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 337.92×270.336 mm |
| obris | 358.5×296.5×17.5 mm |
| površinski | Antiglare (Haze 25%), Hard coating (3H) |
| svjetlina | 300 cd/m² (Typ.) |
| omjer kontrasta | 1000:1 (Typ.) |
| boje prikaza | 16.7M (6-bit + Hi-FRC), CIE193172% |
| vrijeme odziva | 1.3/3.7 (Typ.)(Tr/Td) |
| kut gledanja | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 4 pcsCCFLWithout Driver |
| signalno sučelje | LVDS (2 ch, 8-bit), 30 pins |
| ulazni napon | 5.0V (Typ.) |
| primjena | DMPC |
| LTM170E4-P01 | Samsung | 17.0 | 1280×1024 |
| LTM170E8-L02 | Samsung | 17.0 | 1280×1024 |
| LTM170E8-L03 | Samsung | 17.0 | 1280×1024 |
| LTM170E8-L21 | Samsung | 17.0 | 1280×1024 |
| LTM170EI-A01 | Samsung | 17.0 | 1280×1024 |
| LTM170ET01 | Samsung | 17.0 | 1280×1024 |
| LTM170EU-L01 | Samsung | 17.0 | 1280×1024 |
| LTM170EU-L31 | Samsung | 17.0 | 1280×1024 |
| LTM170EX-L31 | Samsung | 17.0 | 1280×1024 |
| LTM170W1-L01 | Samsung | 17.0 | 1280×768 |
| HM185WX1-400 | BOE | 18.5 | 1366×768 |
| HSD170ME13-A05 | HannStar | 17.0 | 1280×1024 |
| LM230WF3-SSA1 | LG Display | 23.0 | 1920×1080 |
| LM250WF2-TLA1 | LG Display | 25.0 | 1920×1080 |
| LTM201U1-L01 | Samsung | 20.1 | 1600×1200 |
| LTM213U3-L07 | Samsung | 21.3 | 1600×1200 |
| M170EG01 V9 | AUO | 17.0 | 1280×1024 |
| M240HW01 V1 | AUO | 24.0 | 1920×1080 |
| MT190AW02 V.V | Innolux | 19.0 | 1440×900 |
| TX43D21VC0CAA | JDI | 17.0 | 1280×1024 |
