| Broj dijela | HM200WD1-100 |
| Marka | BOE |
| Veličina | 20.0 |
| Primjena | DMPC |
| Rezolucija | 1600×900 |
| Sastav | LCM |
| Svjetlina | 250 |
| CR | 1000:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | BOE |
| panelni model | HM200WD1-100 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 20.0 inch |
| rezolucija | 1600(RGB)×900 , HD+ |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 442.8×249.075 mm |
| obris | 462.8×272 mm |
| površinski | Antiglare (Haze 25%), Hard coating (3H) |
| svjetlina | 250 cd/m² (Typ.) |
| omjer kontrasta | 1000:1 (Typ.) |
| boje prikaza | 16.7M (6-bit + Hi-FRC) |
| vrijeme odziva | 1.5/3.5 (Typ.)(Tr/Td) |
| kut gledanja | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 13S4PWLEDWithout Driver |
| signalno sučelje | LVDS (2 ch, 8-bit), 30 pins |
| ulazni napon | 5.0V (Typ.) |
| primjena | DMPC |
