| Broj dijela | MT230DW01 V.0 |
| Marka | Innolux |
| Veličina | 23.0 |
| Primjena | DMPC |
| Rezolucija | 1920×1080 |
| Sastav | LCM |
| Svjetlina | 300 |
| CR | 1000:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | LVDS |
| marka panela | INNOLUX |
| panelni model | MT230DW01 V.0 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 23.0 inch |
| rezolucija | 1920(RGB)×1080 , FHD |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 509.184×286.416 mm |
| obris | 533.2×312 mm |
| površinski | Antiglare (Haze 25%), Hard coating (3H) |
| svjetlina | 300 cd/m² (Typ.) |
| omjer kontrasta | 1000:1 (Typ.) |
| boje prikaza | 16.7M (6-bit + Hi-FRC), CIE193172% |
| vrijeme odziva | 1.5/3.5 (Typ.)(Tr/Td) |
| kut gledanja | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 4 pcsCCFL |
| signalno sučelje | LVDS (2 ch, 8-bit), 30 pins |
| ulazni napon | 5.0V (Typ.) |
| primjena | DMPC |
| LC230W01-A2 | LG Display | 23.0 | 1280×768 |
| LM230WF1-TLA5 | LG Display | 23.0 | 1920×1080 |
| LM230WF3-SLB2 | LG Display | 23.0 | 1920×1080 |
| LM230WF3-SLL1 | LG Display | 23.0 | 1920×1080 |
| LM230WF5-TLD2 | LG Display | 23.0 | 1920×1080 |
| LM230WF5-TRA2 | LG Display | 23.0 | 1920×1080 |
| LTA230A172F | TOSHIBA | 23.0 | 1280×768 |
| LTM230HT02 | Samsung | 23.0 | 1920×1080 |
| LTM230HT09 | Samsung | 23.0 | 1920×1080 |
| MT230DW01 V.0 | Innolux | 23.0 | 1920×1080 |
| HR236WU1-100 | BOE | 23.6 | 1920×1080 |
| HT170EX1-300 | BOE | 17.0 | 1280×1024 |
| LM185WH1-TLH1 | LG Display | 18.5 | 1366×768 |
| LM190E09-TLD1 | LG Display | 19.0 | 1280×1024 |
| LM200WD3-TLF2 | LG Display | 20.0 | 1600×900 |
| LQ315D1JG03 | SHARP | 31.5 | 3840×2160 |
| LTM220M1-L02(Glare) | Samsung | 22.0 | 1680×1050 |
| LTM270RL01 | Samsung | 27.0 | 5120×2880 |
| M185XW01 V8 | AUO | 18.5 | 1366×768 |
| M215HTN01.0 | AUO | 21.5 | 1920×1080 |
