| Broj dijela | LS037V7DW01 |
| Marka | SHARP |
| Veličina | 3.7 |
| Primjena | HHP |
| Rezolucija | 480×640 |
| Sastav | LCM |
| Svjetlina | 165 |
| CR | 200:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | SHARP |
| panelni model | LS037V7DW01 |
| vrsta panela | CG-Silicon , LCM |
| veličina ploče | 3.7 inch |
| rezolucija | 480(RGB)×640 , VGA |
| način prikaza | Normally Black, Transflective |
| aktivno područje | 56.16×74.88 mm |
| obris | 65×89.2×6.4 mm |
| površinski | Hard coating (3H) |
| svjetlina | 165 cd/m² (Typ.) |
| omjer kontrasta | 200:1 (Typ.)(Transmissive)2:1 (Typ.)(Reflective) |
| boje prikaza | 262K (6-bit), CIE193135% |
| vrijeme odziva | 15/20 (Typ.)(Tr/Td) |
| kut gledanja | 80/80/80/80 (Typ.)(CR≥5)(L/R/U/D) |
| tip svjetiljke | WLED |
| signalno sučelje | Parallel RGB (1 ch, 6-bit), 51 pins |
| ulazni napon | 3.3V (Typ.)(VSHD) |
| primjena | HHP |
