| Broj dijela | LQ043T1DG03B |
| Marka | SHARP |
| Veličina | 4.3 |
| Primjena | HHP |
| Rezolucija | 480×272 |
| Sastav | LCM |
| Svjetlina | 500 |
| CR | 300:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | SHARP |
| panelni model | LQ043T1DG03B |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 4.3 inch |
| rezolucija | 480(RGB)×272 , WQVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 95.04×53.856 mm |
| obris | 105.5×67.2×5.35 mm |
| površinski | Antiglare, Hard coating (2H) |
| svjetlina | 500 cd/m² (Typ.) |
| omjer kontrasta | 300:1 (Typ.) |
| boje prikaza | 16.7M (8-bit) |
| vrijeme odziva | 30/30 (Typ.)(Tr/Td) |
| kut gledanja | 45/45/20/55 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 9S1PWLEDWithout Driver |
| signalno sučelje | Parallel RGB (1 ch, 8-bit), 40 pins |
| ulazni napon | 3.3/5.0V (Typ.)(VCC/AVDD) |
| primjena | HHP |
| LQ043T1DG03B | SHARP | 4.3 | 480×272 |
| LQ043T1DG28 | SHARP | 4.3 | 480×272 |
| LQ043T1DH01 | SHARP | 4.3 | 480×272 |
| LQ043T1DH42 | SHARP | 4.3 | 480×272 |
| LQ043T1LX01A | SHARP | 4.3 | 540×960 |
| LQ043T3DG02 | SHARP | 4.3 | 480×272 |
| LQ043T3DX04 | SHARP | 4.3 | 480×272 |
| LQ043T3DX0E | SHARP | 4.3 | 480×272 |
| LQ043T3DX0G | SHARP | 4.3 | 480×272 |
| LQ043T3LX02 | SHARP | 4.3 | 480×272 |
| 24QVW1H | SII | 2.4 | 240×320 |
| COM35T3112DTR | ORTUSTECH | 3.5 | 240×320 |
| COM40T4M46ULX | ORTUSTECH | 4.0 | 480×800 |
| LH300Q01-ED01 | LG Display | 3.0 | 320×240 |
| LM038QC1R10 | SHARP | 3.8 | 320×240 |
| LQ038B7DB01 | SHARP | 3.8 | 320×480 |
| LQ040Y3DX80B | SHARP | 4.0 | 480×800 |
| LS037V7DW06 | SHARP | 3.7 | 480×640 |
| LTM035A776C | TOSHIBA | 3.5 | 240×320 |
| TX09D30VM1CCA | KOE | 3.5 | 240×320 |
