| Broj dijela | COM40T4M46ULX |
| Marka | ORTUSTECH |
| Veličina | 4.0 |
| Primjena | HHP |
| Rezolucija | 480×800 |
| Sastav | LCM |
| Svjetlina | 400 |
| CR | 700:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | ORTUSTECH |
| panelni model | COM40T4M46ULX |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 4.0 inch |
| rezolucija | 480(RGB)×800 , WVGA |
| način prikaza | Buenaview, Normally Black, Transmissive |
| aktivno područje | 51.84×86.4 mm |
| obris | 57.2×97.9 mm |
| površinski | Hard coating (3H) |
| svjetlina | 400 cd/m² (Typ.) |
| omjer kontrasta | 700:1 (Min.) |
| boje prikaza | 16.7M (8-bit), CIE193170% |
| vrijeme odziva | 18/17 (Typ.)(Tr/Td) |
| kut gledanja | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 1S7PWLEDWithout Driver |
| signalno sučelje | Parallel RGB (1 ch, 8-bit) + SPI, 50 pins |
| ulazni napon | 1.8/2.8V (Typ.)(IOVCC/VCC) |
| primjena | HHP |
