| Broj dijela | AM-320240LATNQW-00H-F |
| Marka | AMPIRE |
| Veličina | 3.5 |
| Primjena | HHP |
| Rezolucija | 320×240 |
| Sastav | LCM |
| Svjetlina | 500 |
| CR | 300:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | AMPIRE |
| panelni model | AM-320240LATNQW-00H-F |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 3.5 inch |
| rezolucija | 320(RGB)×240 , QVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 70.08×52.56 mm |
| obris | 77.8×64.5×4.7 mm |
| površinski | Antiglare |
| svjetlina | 500 cd/m² (Typ.) |
| omjer kontrasta | 300:1 (Typ.) |
| boje prikaza | 262K (6-bit) |
| vrijeme odziva | 50 (Typ.)(Tr+Td) |
| kut gledanja | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 3S2PWLEDWithout Driver |
| signalno sučelje | Parallel RGB (1 ch, 6-bit), 40 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | HHP |
