| Broj dijela | DLC0350BMG-1 |
| Marka | Other |
| Veličina | 3.5 |
| Primjena | MPH |
| Rezolucija | 240×320 |
| Sastav | LCM |
| Svjetlina | 100 |
| CR | 150:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | DLC |
| panelni model | DLC0350BMG-1 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 3.5 inch |
| rezolucija | 240(RGB)×320 , QVGA |
| način prikaza | TN, Normally White, Transflective |
| aktivno područje | 53.64×71.52 mm |
| obris | 64×85×3.13 mm |
| površinski | Hard coating |
| svjetlina | 100 cd/m² (Typ.) |
| omjer kontrasta | 150:1 (Typ.)(Transmissive)6.5:1 (Typ.)(Reflective) |
| boje prikaza | 262K (6-bit) |
| vrijeme odziva | 35 (Typ.)(Tr+Td) |
| kut gledanja | 40/45/55/40 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 6S1PWLEDWithout Driver |
| signalno sučelje | Parallel RGB (1 ch, 6-bit) + SPI, 50 pins |
| ulazni napon | 2.8/15/-10V (Typ.)(VCC/VGH/VGL) |
| primjena | MPH |
