| Broj dijela | LQ043Y1DX01 |
| Marka | SHARP |
| Veličina | 4.3 |
| Primjena | MPH |
| Rezolucija | 480×800 |
| Sastav | LCM |
| Svjetlina | 350 |
| CR | 900:1 |
| Boje | 65K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | SHARP |
| panelni model | LQ043Y1DX01 3 Compatible model |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 4.3 inch |
| rezolucija | 480(RGB)×800 , WVGA |
| način prikaza | ASV, Normally Black, Transmissive |
| aktivno područje | 56.16×93.6 mm |
| obris | 62.46×105.9×2.3 mm |
| površinski | Hard coating (3H) |
| svjetlina | 350 cd/m² (Typ.) |
| omjer kontrasta | 900:1 (Typ.) |
| boje prikaza | 65K , CIE193172% |
| vrijeme odziva | 35 (Typ.)(Tr+Td) |
| kut gledanja | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 8S1PWLEDWithout Driver |
| signalno sučelje | Parallel RGB, 45 pins |
| ulazni napon | 3.0/2.6V (Typ.)(VCI/VDDIO) |
| primjena | MPH |
| LQ043T1DG01 | SHARP | 4.3 | 480×272 |
| LQ043T1DG02 | SHARP | 4.3 | 480×272 |
| LQ043T1DG03B | SHARP | 4.3 | 480×272 |
| LQ043T1DG28 | SHARP | 4.3 | 480×272 |
| LQ043T3DG01 | SHARP | 4.3 | 480×272 |
| LQ043T3DX02 | SHARP | 4.3 | 480×272 |
| LQ043T3DX0E | SHARP | 4.3 | 480×272 |
| LQ043T3LX02 | SHARP | 4.3 | 480×272 |
| LQ043Y1DX01 | SHARP | 4.3 | 480×800 |
| LQ043Y1DX03D | SHARP | 4.3 | 480×800 |
| AMS369FG06-0 | Samsung | 3.7 | 480×800 |
| CM546B1-002 | CSOT | 5.5 | 1080×1920 |
| H497DAN01.0 | AUO | 5.0 | 1080×1920 |
| HVA42WV1-M00 | HYDIS | 4.2 | 480×800 |
| LH400WV3-SD04 | LG Display | 4.0 | 480×800 |
| LH550WF4-SD01 | LG Display | 5.5 | 1080×1920 |
| LS050T1SX01 | SHARP | 5.0 | 1080×1920 |
| LTM030DH60 | TOSHIBA | 3.0 | 240×427 |
| TM032PDZ13 | Tianma | 3.2 | 320×480 |
| TM055JVZG02 | Tianma | 5.5 | 720×1280 |
