| Broj dijela | LH550WF4-SD01 |
| Marka | LG Display |
| Veličina | 5.5 |
| Primjena | MPH |
| Rezolucija | 1080×1920 |
| Sastav | Assembly |
| Svjetlina | 550 |
| CR | 1600:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | MIPI |
| marka panela | LG Display |
| panelni model | LH550WF4-SD01 |
| vrsta panela | LTPS TFT-LCD , Assembly |
| veličina ploče | 5.5 inch |
| rezolucija | 1080(RGB)×1920 , FHD |
| aktivno područje | 68.364×121.536 mm |
| obris | 75.27×155.55×2.35 mm |
| površinski | |
| svjetlina | 550 cd/m² (Typ.) |
| omjer kontrasta | 1600:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE193170% |
| kut gledanja | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| signalno sučelje | MIPI (4 data lanes), 36 pins |
| ulazni napon | 1.8//5.7/-5.7V (Typ.)(DVDD/AVDDH/AVDDN) |
| primjena | MPH |
