| Broj dijela | LH550WF1-SD01 |
| Marka | LG Display |
| Veličina | 5.5 |
| Primjena | MPH |
| Rezolucija | 1080×1920 |
| Sastav | LCM |
| Svjetlina | 450 |
| CR | 1000:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | MIPI |
| marka panela | LG Display |
| panelni model | LH550WF1-SD01 |
| vrsta panela | LTPS TFT-LCD , LCM |
| veličina ploče | 5.5 inch |
| rezolucija | 1080(RGB)×1920 , FHD |
| način prikaza | IPS, Normally Black, Transmissive |
| aktivno područje | 68.04×120.96 mm |
| obris | 71.14×128.01 mm |
| površinski | Antireflection |
| svjetlina | 450 cd/m² (Typ.) |
| omjer kontrasta | 1000:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE193170% |
| vrijeme odziva | 17/18 (Typ.)(Tr/Td) |
| kut gledanja | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 6S2PWLEDWithout Driver |
| signalno sučelje | MIPI (4 data lanes), 30 pins |
| ulazni napon | 1.8/5.0/-5.0V (Typ.)(IOVCC/VSP/VSN) |
| primjena | MPH |
