| Broj dijela | LH550WF2-SD03 |
| Marka | LG Display |
| Veličina | 5.5 |
| Primjena | MPH |
| Rezolucija | 1080×1920 |
| Sastav | LCM |
| Svjetlina | 460 |
| CR | 1000:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | MIPI |
| marka panela | LG Display |
| panelni model | LH550WF2-SD03 |
| vrsta panela | LTPS TFT-LCD , LCM |
| veličina ploče | 5.5 inch |
| rezolucija | 1080(RGB)×1920 , FHD |
| način prikaza | AH3-IPS, Normally Black, Transmissive |
| aktivno područje | 68.04×120.96 mm |
| obris | 70.94×128.01×1.55 mm |
| površinski | |
| svjetlina | 460 cd/m² (Typ.) |
| omjer kontrasta | 1000:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE193170% |
| vrijeme odziva | 25 (Typ.)(Tr+Td) |
| kut gledanja | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 6S2PWLEDWithout Driver |
| signalno sučelje | MIPI (4 data lanes), 50 pins |
| ulazni napon | 1.8/5.0/-5.0V (Typ.)(VDD/VAN/VPG) |
| primjena | MPH |
