| Broj dijela | UG-5664ASGGF01 |
| Marka | WiseChip |
| Veličina | 5.5 |
| Primjena | IA |
| Rezolucija | 256×64 |
| Sastav | OLED |
| Svjetlina | 80 |
| CR | 2000:1 |
| Boje | Grayscale(G) |
| Pozadinsko osvjetljenje | self |
| Sučelje | CPU/SPI |
| marka panela | Univision |
| panelni model | UG-5664ASGGF01 |
| vrsta panela | PM-OLED , OLED |
| veličina ploče | 5.5 inch |
| rezolucija | 256×64 |
| aktivno područje | 135.65×33.89 mm |
| obris | 146×45×2.1 mm |
| površinski | |
| svjetlina | 80 cd/m² (Typ.) |
| omjer kontrasta | 2000 : 1 (Typ.) |
| boje prikaza | Grayscale(G) (4-bit) |
| kut gledanja | 80/80/80/80 (Min.)(L/R/U/D) |
| vozač ic | COF Built-in SSD1322 |
| signalno sučelje | 8-bit 6800/8080 parallel, 3/4-wire SPI, 30 pins |
| ulazni napon | 2.8/15V (Typ.)(VCI/VCC) |
| rohs: | |
| primjena | IA |
