| Broj dijela | LTM030DH60 |
| Marka | TOSHIBA |
| Veličina | 3.0 |
| Primjena | MPH |
| Rezolucija | 240×427 |
| Sastav | CELL |
| Svjetlina | 0 |
| CR | 800:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | No B/L |
| Sučelje | M-CMADS |
| marka panela | TOSHIBA |
| panelni model | LTM030DH60 |
| vrsta panela | LTPS TFT-LCD , CELL |
| veličina ploče | 3.0 inch |
| rezolucija | 240(RGB)×427 |
| način prikaza | TN, Normally White, Transflective |
| aktivno područje | 36.72×65.33 mm |
| obris | 40.52×72.63 mm |
| površinski | |
| dubina stakla | 0.10+0.20 mm |
| transmisivnost | 5.4% (Typ.)(with Polarizer) |
| omjer kontrasta | 800:1 (Typ.)(Transmissive)4:1 (Typ.)(Reflective) |
| boje prikaza | 262K , CIE193164% |
| vrijeme odziva | 45/45 (Typ.)(Tr/Td) |
| kut gledanja | 70/70/70/70 (Min.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| signalno sučelje | M-CMADS + SPI, 22 pins |
| ulazni napon | 2.8/1.8V (Typ.)(VCC/VDDIO) |
| primjena | MPH |
