| Broj dijela | H380VW01 V2 |
| Marka | AUO |
| Veličina | 3.8 |
| Primjena | MPH |
| Rezolucija | 480×800 |
| Sastav | LCM |
| Svjetlina | 450 |
| CR | 700:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | AUO |
| panelni model | H380VW01 V2 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 3.8 inch |
| rezolucija | 480(RGB)×800 , WVGA |
| način prikaza | AHVA, Normally Black, Transmissive |
| aktivno područje | 49.68×82.8 mm |
| obris | 53.94×116.49 mm |
| površinski | |
| svjetlina | 450 cd/m² (Typ.) |
| omjer kontrasta | 700:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE193170% |
| vrijeme odziva | 20/15 (Typ.)(Tr/Td) |
| kut gledanja | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 4S2PWLEDWithout Driver |
| signalno sučelje | Parallel RGB (1 ch, 8-bit) + SPI, 60 pins |
| ulazni napon | 1.8/3.0V (Typ.)(IOVDD/AVDD) |
| primjena | MPH |
