| Broj dijela | SP10Q010 |
| Marka | KOE |
| Veličina | 3.8 |
| Primjena | IA |
| Rezolucija | 320×240 |
| Sastav | LCM |
| Svjetlina | 110 |
| CR | 20:1 |
| Boje | Monochrome |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | Parallel Data |
| marka panela | KOE |
| panelni model | SP10Q010 |
| vrsta panela | FSTN-LCD , LCM |
| veličina ploče | 3.8 inch |
| rezolucija | 320×240 , QVGA |
| način prikaza | STN, Black/White (Negative), Transmissive |
| aktivno područje | 76.79×57.59 mm |
| obris | 94.7×73.3×6 mm |
| površinski | Glare (Haze 0%) |
| svjetlina | 110 cd/m² (Typ.) |
| omjer kontrasta | 20:1 (Typ.) |
| boje prikaza | Monochrome |
| vrijeme odziva | 150/350 (Typ.)(Tr/Td) |
| kut gledanja | 80 (Typ.)(CR≥2, Φ2-Φ1)(L/R/U/D) |
| frekvencija | 75Hz |
| tip svjetiljke | 1S6PWLEDWithout Driver |
| signalno sučelje | Parallel Data (4-bit), 20 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | IA |
