| Broj dijela | LH530QH1-SD01 |
| Marka | LG Display |
| Veličina | 5.3 |
| Primjena | MPH |
| Rezolucija | 1440×2560 |
| Sastav | Assembly |
| Svjetlina | 500 |
| CR | 1500:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | MIPI |
| marka panela | LG Display |
| panelni model | LH530QH1-SD01 |
| vrsta panela | LTPS TFT-LCD , Assembly |
| veličina ploče | 5.3 inch |
| rezolucija | 1440(RGB)×2560 , Quad-HD |
| aktivno područje | 65.88×117.12 mm |
| obris | 70.3×135.19×1.86 mm |
| površinski | Hard coating |
| svjetlina | 500 cd/m² (Typ.) |
| omjer kontrasta | 1500:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE193185% |
| kut gledanja | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| signalno sučelje | MIPI (2 ch, 4 data lanes), 54 pins |
| ulazni napon | 1.8/3.3/5.4/-5.4V (Typ.)(VDDI/VPNL/DDVDH/DDVDL) |
| primjena | MPH |
