| Broj dijela | LH300WQ1-ED01 |
| Marka | LG Display |
| Veličina | 3.0 |
| Primjena | MPH |
| Rezolucija | 240×400 |
| Sastav | OLED |
| Svjetlina | 210 |
| CR | 2000:1 |
| Boje | 65K/262K |
| Pozadinsko osvjetljenje | self |
| Sučelje | CPU/RGB/SPI |
| marka panela | LG Display |
| panelni model | LH300WQ1-ED01 |
| vrsta panela | AM-OLED , OLED |
| veličina ploče | 3.0 inch |
| rezolucija | 240(RGB)×400 , WQVGA |
| aktivno područje | 38.88×64.8 mm |
| obris | 44×74.6 mm |
| površinski | Hard coating |
| svjetlina | 210 cd/m² (Typ.) |
| omjer kontrasta | 2000 : 1 (Min.) |
| boje prikaza | 65K/262K , CIE193185% |
| kut gledanja | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| signalno sučelje | 8/9/16/18-bit 6800/8080 parallel, 6/16/18-bit RGB, SPI, 40 pins |
| ulazni napon | 2.8/2.8/3.7V (Typ.)(VDD/VCC/VBATT) |
| primjena | MPH |
