| Broj dijela | LQ043Y1DX03D |
| Marka | SHARP |
| Veličina | 4.3 |
| Primjena | MPH |
| Rezolucija | 480×800 |
| Sastav | LCM |
| Svjetlina | 340 |
| CR | 900:1 |
| Boje | 65K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | SHARP |
| panelni model | LQ043Y1DX03D |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 4.3 inch |
| rezolucija | 480(RGB)×800 , WVGA |
| način prikaza | ASV, Normally Black, Transmissive |
| aktivno područje | 56.16×93.6 mm |
| obris | 62.46×105.9 mm |
| površinski | Hard coating (3H) |
| svjetlina | 340 cd/m² (Typ.) |
| omjer kontrasta | 900:1 (Typ.) |
| boje prikaza | 65K , CIE193172% |
| vrijeme odziva | 35 (Max.)(Tr+Td) |
| kut gledanja | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 8S1PWLEDWithout Driver |
| signalno sučelje | Parallel RGB, 45 pins |
| ulazni napon | 3.3/2.6V (Typ.)(VCI/VDDIO) |
| primjena | MPH |
