| Broj dijela | TM047XDZP02 |
| Marka | Tianma |
| Veličina | 4.7 |
| Primjena | MPH |
| Rezolucija | 540×960 |
| Sastav | LCM |
| Svjetlina | 400 |
| CR | 1000:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | MIPI |
| marka panela | TIANMA |
| panelni model | TM047XDZP02 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 4.7 inch |
| rezolucija | 540(RGB)×960 , qHD |
| način prikaza | SFT, Normally Black, Transmissive |
| aktivno područje | 58.32×103.68 mm |
| obris | 62.72×113.53×1.78 mm |
| površinski | |
| svjetlina | 400 cd/m² (Typ.) |
| omjer kontrasta | 1000:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE193170% |
| vrijeme odziva | 25 (Typ.)(Tr+Td) |
| kut gledanja | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 5S2PWLEDWithout Driver |
| signalno sučelje | MIPI (2 data lanes), 24 pins |
| ulazni napon | (1.8/2.8)/2.8V (Typ.)(IOVCC/VCC) |
| primjena | MPH |
