| Broj dijela | LQ043T1LX01A |
| Marka | SHARP |
| Veličina | 4.3 |
| Primjena | MPH |
| Rezolucija | 540×960 |
| Sastav | LCM |
| Svjetlina | 500 |
| CR | 1000:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | MDDI/MIPI |
| marka panela | SHARP |
| panelni model | LQ043T1LX01A |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 4.3 inch |
| rezolucija | 540(RGB)×960 , qHD |
| način prikaza | ASV, Normally Black, Transmissive |
| aktivno područje | 53.46×95.04 mm |
| obris | 58.54×105.7 mm |
| površinski | Hard coating (3H) |
| svjetlina | 500 cd/m² (Typ.) |
| omjer kontrasta | 1000:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE193170% |
| vrijeme odziva | 35 (Max.)(Tr+Td) |
| kut gledanja | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| tip svjetiljke | 10S1PWLEDWithout Driver |
| signalno sučelje | MDDI/MIPI, 25 pins |
| ulazni napon | 1.8/3.1V (Typ.)(IOVDD/AVDD) |
| primjena | MPH |
