| Broj dijela | LS037V7DD06 |
| Marka | SHARP |
| Veličina | 3.7 |
| Primjena | MPH |
| Rezolucija | 480×640 |
| Sastav | LCM |
| Svjetlina | 100 |
| CR | 100:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | SHARP |
| panelni model | LS037V7DD06 |
| vrsta panela | CG-Silicon , LCM |
| veličina ploče | 3.7 inch |
| rezolucija | 480(RGB)×640 , VGA |
| način prikaza | TN, Normally White, Transflective |
| aktivno područje | 56.16×74.88 mm |
| obris | 65×90 mm |
| površinski | |
| svjetlina | 100 cd/m² (Typ.) |
| omjer kontrasta | 100:1 (Typ.)(Transmissive)5:1 (Typ.)(Reflective) |
| boje prikaza | 262K (6-bit) |
| vrijeme odziva | 30/50 (Typ.)(Tr/Td) |
| kut gledanja | 40/40/40/40 (Typ.)(CR≥2)(L/R/U/D) |
| tip svjetiljke | WLED |
| signalno sučelje | Parallel RGB (1 ch, 6-bit), 51 pins |
| ulazni napon | 5.0/3.3/8.0/-4.0/-8.0V (Typ.)(VSHA/VSHD/VDD/VSSD/GVSS) |
| primjena | MPH |
