| Broj dijela | DLC0350FVG-5 |
| Marka | Other |
| Veličina | 3.5 |
| Primjena | DSC |
| Rezolucija | 320×240 |
| Sastav | LCM |
| Svjetlina | 300 |
| CR | 350:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | Parallel/Serial |
| marka panela | DLC |
| panelni model | DLC0350FVG-5 1 Compatible model |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 3.5 inch |
| rezolucija | 320(RGB)×240 , QVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 70.08×52.56 mm |
| obris | 76.9×64×3.25 mm |
| površinski | |
| svjetlina | 300 cd/m² (Typ.) |
| omjer kontrasta | 350:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE193160% |
| vrijeme odziva | 50 (Typ.)(Tr+Td) |
| kut gledanja | 60/60/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| tip svjetiljke | 6S1PWLEDWithout Driver |
| signalno sučelje | Digital RGB (8/24-bit) + SPI, CCIR601/656, 54 pins |
| ulazni napon | 3.3V (Typ.)(VCC) |
| primjena | DSC |
| A024CN02 VJ | AUO | 2.4 | 480×234 |
| A027DTN01.3 | AUO | 2.7 | 320×240 |
| A030DW01 V1 | AUO | 3.0 | 320×240 |
| CLAA030HA22DE | CPT | 3.0 | 960×480(dot) |
| CT025TN01 | Innolux | 2.5 | 320×240 |
| FX020410DNSWBG01 | Data Image | 2.4 | 480×234 |
| LQ035NC211 | Innolux | 3.5 | 320×240 |
| LS027T3DG01 | SHARP | 2.7 | 320×240 |
| TD030MHEB3 | TPO | 3.0 | 320×240 |
| TM035KDH16-09 | Tianma | 3.5 | 320×240 |
