| Broj dijela | LQ035NC211 |
| Marka | Innolux |
| Veličina | 3.5 |
| Primjena | DSC |
| Rezolucija | 320×240 |
| Sastav | LCM |
| Svjetlina | 200 |
| CR | 400:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | Parallel/Serial |
| marka panela | ChiHsin |
| panelni model | LQ035NC211 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 3.5 inch |
| rezolucija | 320(RGB)×240 , QVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 70.08×52.56 mm |
| obris | 76.9×63.9×4.56 mm |
| površinski | Antiglare (Haze 20%) |
| svjetlina | 200 cd/m² (Typ.) |
| omjer kontrasta | 400:1 (Typ.) |
| boje prikaza | 16.7M , CIE193160% |
| vrijeme odziva | 10/15 (Typ.)(Tr/Td) |
| kut gledanja | 60/60/50/55 (Typ.)(CR≥10)(L/R/U/D) |
| tip svjetiljke | 6S1PWLEDWithout Driver |
| signalno sučelje | Digital RGB (8/24-bit) + SPI, CCIR601/656, 54 pins |
| ulazni napon | 3.3V (Typ.)(VCC) |
| primjena | DSC |
| LQ035NC211 | Innolux | 3.5 | 320×240 |
| LQ035Q1DG01 | SHARP | 3.5 | 320×240 |
| LQ035Q1DG02 | SHARP | 3.5 | 320×240 |
| LQ035Q1DH01 | SHARP | 3.5 | 320×240 |
| LQ035Q7DB03F | SHARP | 3.5 | 240×320 |
| LQ035Q7DB04 | SHARP | 3.5 | 240×320 |
| LQ035Q7DB05 | SHARP | 3.5 | 240×320 |
| LQ035Q7DH02 | SHARP | 3.5 | 240×320 |
| LQ035Q7DH05 | SHARP | 3.5 | 240×320 |
| LQ035Q7DH06 | SHARP | 3.5 | 240×320 |
| A027DN01 VQ | AUO | 2.7 | 320×240 |
| A027DN03 V3 | AUO | 2.7 | 320×240 |
| A027DN04 V4 | AUO | 2.7 | 320×240 |
| L3F04X-80300C | Epson | 0.48 | 1024×768 |
| LQ035JC211 | Innolux | 3.5 | 320×240 |
| LTV350QV-F04 | Samsung | 3.5 | 320×240 |
| PA025XSC | E Ink | 2.5 | 480×234 |
| PD035OX1 | E Ink | 3.5 | 320×234 |
| TD024THEB5 | TPO | 2.4 | 480×240 |
| TD025THEG1 | TPO | 2.5 | 320×240 |
