| Broj dijela | COM35T3112DTR |
| Marka | ORTUSTECH |
| Veličina | 3.5 |
| Primjena | HHP |
| Rezolucija | 240×320 |
| Sastav | LCM |
| Svjetlina | 100 |
| CR | 60:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | CASIO |
| panelni model | COM35T3112DTR |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 3.5 inch |
| rezolucija | 240(RGB)×320 , QVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 52.56×70.08 mm |
| obris | 67.9×84.5×5.4 mm |
| površinski | |
| svjetlina | 100 cd/m² (Typ.) |
| omjer kontrasta | 60:1 (Min.) |
| boje prikaza | 262K (6-bit) |
| vrijeme odziva | 40/60 (Max.)(Tr/Td) |
| kut gledanja | 50/50/60/20 (Min.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 6S1PWLEDWithout Driver |
| signalno sučelje | Parallel RGB (1 ch, 8-bit), 45 pins |
| ulazni napon | 3.0V (Typ.) |
| primjena | HHP |
