| Broj dijela | DMC-16117A |
| Marka | Kyocera |
| Veličina | 2.4 |
| Primjena | |
| Rezolucija | 16×1 |
| Sastav | LCM |
| Svjetlina | |
| CR | |
| Boje | Monochrome |
| Pozadinsko osvjetljenje | No B/L |
| Sučelje | CPU |
| marka panela | OPTREX |
| panelni model | DMC-16117A |
| vrsta panela | TN-LCD , LCM |
| veličina ploče | 2.4 inch |
| format prikaza | 16 characters × 1 lines |
| način prikaza | TN, Reflective |
| prikaz fontova | 5×8 dots |
| veličina znaka | 3.2×5.95 mm |
| visina lika | 3.75×5.95 mm |
| aktivno područje | 59.4×5.95 mm |
| područje okvira | 64.5×13.0 mm |
| obris | 80×36×10 mm |
| svjetlina | |
| omjer kontrasta | 3.5:1 (Typ.)(Reflective) |
| boje prikaza | Monochrome |
| vrijeme odziva | 180/130 (Typ.)(Tr/Td) |
| tip svjetiljke | No B/L |
| signalno sučelje | 8-bit parallel, 14 pins |
| ulazni napon | 5.0V (Typ.) |
