| Broj dijela | TD043MTEA1 |
| Marka | TPO |
| Veličina | 4.3 |
| Primjena | |
| Rezolucija | 800×480 |
| Sastav | LCM |
| Svjetlina | 300 |
| CR | 400:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | TPO |
| panelni model | TD043MTEA1 |
| vrsta panela | LTPS TFT-LCD , LCM |
| veličina ploče | 4.3 inch |
| rezolucija | 800(RGB)×480 , WVGA |
| način prikaza | Normally Black, Transmissive |
| aktivno područje | 93.6×56.16 mm |
| obris | 100.6×68.45 mm |
| površinski | |
| svjetlina | 300 cd/m² (Typ.) |
| omjer kontrasta | 400:1 (Typ.) |
| boje prikaza | 16.7M (8-bit) |
| vrijeme odziva | 30 (Typ.)(Tr+Td) |
| kut gledanja | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 8S1PWLEDWithout Driver |
| signalno sučelje | Parallel RGB (1 ch, 8-bit), 60 pins |
| ulazni napon | 3.3/5.0/-5V (Typ.)(VCC/VDDP/VDDN) |
