| Broj dijela | LS024Q8DD92 |
| Marka | SHARP |
| Veličina | 2.4 |
| Primjena | |
| Rezolucija | 240×320 |
| Sastav | CELL |
| Svjetlina | 0 |
| CR | 100:1 |
| Boje | 65K/262K |
| Pozadinsko osvjetljenje | No B/L |
| Sučelje | TTL |
| marka panela | SHARP |
| panelni model | LS024Q8DD92 |
| vrsta panela | CG-Silicon , CELL |
| veličina ploče | 2.4 inch |
| rezolucija | 240(RGB)×320 , QVGA |
| način prikaza | TN, Normally White, Transflective |
| aktivno područje | 36.72×48.96 mm |
| obris | 41.2×58 mm |
| površinski | Hard coating (3H) |
| dubina stakla | 0.50+0.50 mm |
| omjer kontrasta | 100:1 (Typ.)(Transmissive)8:1 (Typ.)(Reflective) |
| boje prikaza | 65K/262K |
| vrijeme odziva | 13/35 (Typ.)(Tr/Td) |
| kut gledanja | 45/45/35/45 (Typ.)(CR≥3)(L/R/U/D) |
| vozač ic | Built-in uPD161831 |
| signalno sučelje | Parallel RGB (1 ch, 6-bit), 60 pins |
| ulazni napon | 3.0/3.0V (Typ.)(VCC/VDC) |
