| Broj dijela | T-55343GD035JU-LW-AFN |
| Marka | Kyocera |
| Veličina | 3.5 |
| Primjena | HHP |
| Rezolucija | 320×240 |
| Sastav | LCM |
| Svjetlina | 360 |
| CR | 700:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | OPTREX |
| panelni model | T-55343GD035JU-LW-AFN |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 3.5 inch |
| rezolucija | 320(RGB)×240 , QVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 70.08×52.56 mm |
| obris | 79×65×4.2 mm |
| površinski | Antiglare |
| svjetlina | 360 cd/m² (Typ.) |
| omjer kontrasta | 700:1 (Typ.) |
| boje prikaza | 16.7M (8-bit) |
| vrijeme odziva | 8/15 (Typ.)(Tr/Td) |
| kut gledanja | 80/80/80/80 (Typ.)(CR≥5)(L/R/U/D) |
| tip svjetiljke | 6S1PWLEDWithout Driver |
| signalno sučelje | Parallel RGB (1 ch, 8-bit) + SPI, 40 pins |
| ulazni napon | 3.3V (Typ.)(VCC) |
| primjena | HHP |
