| Broj dijela | LQ040Y3DX80 |
| Marka | SHARP |
| Veličina | 4.0 |
| Primjena | HHP |
| Rezolucija | 480×800 |
| Sastav | LCM |
| Svjetlina | 320 |
| CR | 800:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | SHARP |
| panelni model | LQ040Y3DX80 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 4.0 inch |
| rezolucija | 480(RGB)×800 , WVGA |
| način prikaza | New Mode2, Normally Black, Transmissive |
| aktivno područje | 51.84×86.4 mm |
| obris | 57.14×96.85×2 mm |
| površinski | |
| svjetlina | 320 cd/m² (Typ.) |
| omjer kontrasta | 800:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE193170% |
| vrijeme odziva | 40 (Typ.)(Tr+Td) |
| kut gledanja | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | WLEDWithout Driver |
| signalno sučelje | Parallel RGB (1 ch, 8-bit) + SPI, 51 pins |
| ulazni napon | 2.8/1.8V (Typ.)(VCI/IOVCC) |
| primjena | HHP |
