| Broj dijela | LQ050T5DG01 |
| Marka | SHARP |
| Veličina | 5.0 |
| Primjena | CNS |
| Rezolucija | 400×240 |
| Sastav | LCM |
| Svjetlina | 600 |
| CR | 800:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | SHARP |
| panelni model | LQ050T5DG01 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 5.0 inch |
| rezolucija | 400(RGB)×240 , WQVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 108×64.8 mm |
| obris | 120.6×75.2×16.8 mm |
| površinski | Antiglare |
| svjetlina | 600 cd/m² (Typ.) |
| omjer kontrasta | 800:1 (Typ.) |
| boje prikaza | 262K (6-bit), CIE193150% |
| vrijeme odziva | 35 (Typ.)(Tr+Td) |
| kut gledanja | 80/80/80/80 (Typ.)(CR≥5)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 4S2PWLEDWithout Driver |
| signalno sučelje | CMOS (1 ch, 6-bit), 40 pins |
| ulazni napon | 3.3/9.0V (Typ.)(VCC/VDC) |
| primjena | CNS |
| LQ050A3AD01 | SHARP | 5.0 | 320×234 |
| LQ050A5BS01 | SHARP | 5.0 | 320×234 |
| LQ050A5BS02 | SHARP | 5.0 | 320×234 |
| LQ050Q5DR01 | SHARP | 5.0 | 320×240 |
| LQ050T1SX02 | SHARP | 5.0 | 1080×1920 |
| LQ050T1SX05(G) | SHARP | 5.0 | 1080×1920 |
| LQ050T3GG01 | SHARP | 5.0 | 400×234 |
| LQ050T5DG01 | SHARP | 5.0 | 400×240 |
| LQ050T5DG02 | SHARP | 5.0 | 400×240 |
| LQ050T5DW02 | SHARP | 5.0 | 400×240 |
| 70WVW3T | SII | 7.0 | 800×480 |
| C061FW01 V0 | AUO | 6.1 | 480×234 |
| CLAA070LF06CW | CPT | 7.0 | 800×480 |
| LQ042T5DZ01 | SHARP | 4.2 | 480×272 |
| LQ064A5CG01 | SHARP | 6.4 | 480×234 |
| LQ065Y5DG03 | SHARP | 6.5 | 800×480 |
| LQ065Y5DZ01 | SHARP | 6.5 | 800×480 |
| LQ080Y5DZ03 | SHARP | 8.0 | 800×480 |
| LTA070B052F | TOSHIBA | 7.0 | 800×480 |
| ND068-101A1 | 6.8 | 1280×480 |
