| Broj dijela | LQ050T3GG01 |
| Marka | SHARP |
| Veličina | 5.0 |
| Primjena | PDVD |
| Rezolucija | 400×234 |
| Sastav | LCM |
| Svjetlina | 350 |
| CR | 60:1 |
| Boje | Full color |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | Analog |
| marka panela | SHARP |
| panelni model | LQ050T3GG01 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 5.0 inch |
| rezolucija | 400(RGB)×234 |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 111.6×62.9 mm |
| obris | 127.7×80.8×7.6 mm |
| površinski | |
| svjetlina | 350 cd/m² (Typ.) |
| omjer kontrasta | 60:1 (Min.) |
| boje prikaza | Full color |
| vrijeme odziva | 30/50 (Typ.)(Tr/Td) |
| kut gledanja | 65/65/40/65 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 1 pcsCCFLWithout Driver |
| signalno sučelje | TFT Specific Analog RGB, 32 pins |
| ulazni napon | 5.3/10.9/13.0/-10.0V (Typ.)(VSH/VCC/VGH/VGL) |
| primjena | PDVD |
