| Broj dijela | LQ050T5DG02 |
| Marka | SHARP |
| Veličina | 5.0 |
| Primjena | CNS |
| Rezolucija | 400×240 |
| Sastav | LCM |
| Svjetlina | 600 |
| CR | |
| Boje | 262K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | SHARP |
| panelni model | LQ050T5DG02 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 5.0 inch |
| rezolucija | 400(RGB)×240 , WQVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 108×64.8 mm |
| obris | 120.6×75.2 mm |
| površinski | |
| svjetlina | 600 cd/m² (Typ.) |
| omjer kontrasta | |
| boje prikaza | 262K (6-bit) |
| vrijeme odziva | |
| kut gledanja | |
| tip svjetiljke | WLED |
| signalno sučelje | CMOS (1 ch, 6-bit) |
| rohs: | |
| primjena | CNS |
