| Broj dijela | H546TAN01.0 |
| Marka | AUO |
| Veličina | 5.5 |
| Primjena | MPH |
| Rezolucija | 720×1280 |
| Sastav | LCM |
| Svjetlina | 440 |
| CR | 800:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | MIPI |
| marka panela | AUO |
| panelni model | H546TAN01.0 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 5.5 inch |
| rezolucija | 720(RGB)×1280 , WXGA |
| način prikaza | AHVA, Normally Black, Transmissive |
| aktivno područje | 68.04×120.96 mm |
| obris | 72.3×130.39×1.75 mm |
| površinski | |
| svjetlina | 440 cd/m² (Typ.) |
| omjer kontrasta | 800:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE193170% |
| vrijeme odziva | 35 (Max.)(Tr+Td) |
| kut gledanja | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | WLEDWithout Driver |
| signalno sučelje | MIPI (4 data lanes) |
| ulazni napon | 1.8/2.8V (Typ.)(IOVCC/VCI) |
| primjena | MPH |
