| Broj dijela | CLAF055WB41 TXX |
| Marka | CPT |
| Veličina | 5.5 |
| Primjena | MPH |
| Rezolucija | 720×1280 |
| Sastav | CELL |
| Svjetlina | 0 |
| CR | 800:1 |
| Boje | |
| Pozadinsko osvjetljenje | No B/L |
| Sučelje | |
| marka panela | CPT |
| panelni model | CLAF055WB41 TXX 2 Compatible model |
| vrsta panela | a-Si TFT-LCD , CELL |
| veličina ploče | 5.5 inch |
| rezolucija | 720(RGB)×1280 , WXGA |
| način prikaza | HFFS, Normally Black, Transmissive |
| aktivno područje | 68.04×120.96 mm |
| obris | 70.44×128.56 mm |
| površinski | Hard coating |
| dubina stakla | 0.20+0.20 mm |
| transmisivnost | 5.0% (Typ.)(with APCF) |
| omjer kontrasta | 800:1 (Typ.) |
| boje prikaza | , CIE193170% |
| vrijeme odziva | 30 (Typ.)(Tr+Td) |
| kut gledanja | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| vozač ic | Suggest ILI9881, OTM1284A-C1 |
| primjena | MPH |
| ACX567AKM-7 | SONY | 3.2 | 320×480 |
| AMS320FS03 | Samsung | 3.2 | 320×480 |
| AMS347FF01 | Samsung | 3.5 | 360×640 |
| DLC0283FZG-7 | Other | 2.8 | 240×320 |
| LQ024B7UD01 | SHARP | 2.4 | 160×240 |
| LS038Y7DX01 | SHARP | 3.8 | 480×800 |
| LT032MDQ7000 | JDI | 3.2 | 360×480 |
| PJ035MA-02A | Innolux | 3.5 | 320×480 |
| TD028STEB2 | TPO | 2.8 | 240×320 |
| TM055XDHP10 | Tianma | 5.5 | 540×960 |
