| Broj dijela | DLC0283FZG-7 |
| Marka | Other |
| Veličina | 2.8 |
| Primjena | MPH |
| Rezolucija | 240×320 |
| Sastav | LCM |
| Svjetlina | 300 |
| CR | 400:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | CPU/RGB |
| marka panela | DLC |
| panelni model | DLC0283FZG-7 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 2.8 inch |
| rezolucija | 240(RGB)×320 , QVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 43.2×57.6 mm |
| obris | 50×70 mm |
| površinski | |
| svjetlina | 300 cd/m² (Typ.) |
| omjer kontrasta | 400:1 (Typ.) |
| boje prikaza | 262K , CIE193150% |
| vrijeme odziva | 25 (Typ.)(Tr+Td) |
| kut gledanja | 60/60/60/45 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 5S1PWLEDWithout Driver |
| signalno sučelje | CPU/RGB, 39 pins |
| ulazni napon | 1.8/2.8V (Typ.)(IOVCC/VCC) |
| primjena | MPH |
