| Broj dijela | H027QT01 |
| Marka | AUO |
| Veličina | 2.7 |
| Primjena | MPH |
| Rezolucija | 208×320 |
| Sastav | LCM |
| Svjetlina | 60 |
| CR | 50:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | AU Optronics |
| panelni model | H027QT01 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 2.7 inch |
| rezolucija | 208(RGB)×320 |
| način prikaza | TN, Normally White, Transflective |
| aktivno područje | 36.816×56.64 mm |
| obris | 45.8×69.17 mm |
| površinski | |
| svjetlina | 60 cd/m² (Typ.) |
| omjer kontrasta | 50:1 (Typ.)(Transmissive)20:1 (Typ.)(Reflective) |
| boje prikaza | 262K (6-bit) |
| vrijeme odziva | 10/30 (Typ.)(Tr/Td) |
| kut gledanja | 45/45/45/45 (Typ.)(CR≥10)(L/R/U/D) |
| tip svjetiljke | 2S2PWLEDWithout Driver |
| signalno sučelje | Parallel RGB (1 ch, 6-bit), 60 pins |
| ulazni napon | 3.3/5/5/3.3/12/-12V (Typ.)(DVCC/AVDD/AVDD1/AVDD2/VGH/VGL) |
| primjena | MPH |
