| Broj dijela | LQ024B7UD01 |
| Marka | SHARP |
| Veličina | 2.4 |
| Primjena | MPH |
| Rezolucija | 160×240 |
| Sastav | LCM |
| Svjetlina | 28 |
| CR | 110:1 |
| Boje | 65K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | CPU |
| marka panela | SHARP |
| panelni model | LQ024B7UD01 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 2.4 inch |
| rezolucija | 160(RGB)×240 , HQVGA |
| način prikaza | TN, Normally White, Transflective |
| aktivno područje | 33.6×50.4 mm |
| obris | 41.8×66.6 mm |
| površinski | Hard coating (3H) |
| svjetlina | 28 cd/m² (Typ.) |
| omjer kontrasta | 110:1 (Typ.)(Transmissive)12:1 (Typ.)(Reflective) |
| boje prikaza | 65K |
| vrijeme odziva | 30/50 (Typ.)(Tr/Td) |
| kut gledanja | 50/50/60/50 (Typ.)(CR≥10)(L/R/U/D) |
| tip svjetiljke | 2S1PWLEDWithout Driver |
| signalno sučelje | CPU, 24 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | MPH |
