| Broj dijela | G090VTN02.0 |
| Marka | AUO |
| Veličina | 9.0 |
| Primjena | IA |
| Rezolucija | 800×480 |
| Sastav | LCM |
| Svjetlina | 300 |
| CR | 500:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | AUO |
| panelni model | G090VTN02.0 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 9.0 inch |
| rezolucija | 800(RGB)×480 , WVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 198×111.696 mm |
| obris | 211.1×128.4×7.1 mm |
| površinski | Antiglare, Hard coating (3H) |
| svjetlina | 300 cd/m² (Typ.) |
| omjer kontrasta | 500:1 (Typ.) |
| boje prikaza | 16.7M (6-bit + Hi-FRC) |
| vrijeme odziva | 10/15 (Typ.)(Tr/Td) |
| kut gledanja | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | WLEDEmbedded (LED Driver) |
| signalno sučelje | TTL (1 ch, 8-bit), 50 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | IA |
| AA090MC01 | Mitsubishi | 9.0 | 800×480 |
| AT090TN12 V.3 | Innolux | 9.0 | 800×480 |
| ED090NA-01D | Innolux | 9.0 | 1280×800 |
| EE090NA-01C | Innolux | 9.0 | 1280×800 |
| G090VTN02.0 | AUO | 9.0 | 800×480 |
| LTA090B230F | TOSHIBA | 9.0 | 536×328 |
| M090SWP1 R0 | IVO | 9.0 | 800×480 |
| NL8048BC24-09D | NLT | 9.0 | 800×480 |
| TM090JDH01 | Tianma | 9.0 | 1280×800 |
| YXD090TN02-40NM01 | SEBO | 9.0 | 1280×800 |
| AA084VC05 | Mitsubishi | 8.4 | 640×480 |
| EL640.400-CB1 FRA | Lumineq | 9.1 | 640×400 |
| LM64P83L | SHARP | 9.4 | 640×480 |
| LQ9D168K | SHARP | 8.4 | 640×480 |
| NL10276BC20-08 | NLT | 10.4 | 1024×768 |
| NL8060BC31-20 | NLT | 12.1 | 800×600 |
| NL8060BC31-42D | NLT | 12.1 | 800×600 |
| OEL9M0064-W-E | Other | 2.0 | 128×32 |
| OEL9M0078-R-E | Other | 1.45 | 132×16 |
| UG-2864ASYIG01 | WiseChip | 2.7 | 128×64 |
