| Broj dijela | M090SWP1 R0 |
| Marka | IVO |
| Veličina | 9.0 |
| Primjena | CNS |
| Rezolucija | 800×480 |
| Sastav | LCM |
| Svjetlina | 300 |
| CR | 500:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | IVO |
| panelni model | M090SWP1 R0 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 9.0 inch |
| rezolucija | 800(RGB)×480 , WVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 198×111.696 mm |
| obris | 211.1×128.4×7.1 mm |
| površinski | Antiglare, Hard coating (3H) |
| svjetlina | 300 cd/m² (Typ.) |
| omjer kontrasta | 500:1 (Typ.) |
| boje prikaza | 16.7M (6-bit + Hi-FRC), CIE193150% |
| vrijeme odziva | 10/15 (Typ.)(Tr/Td) |
| kut gledanja | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | WLEDEmbedded (LED Driver) |
| signalno sučelje | Parallel RGB (1 ch, 8-bit), 50 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | CNS |
| AA090MC01 | Mitsubishi | 9.0 | 800×480 |
| AT090TN12 V.3 | Innolux | 9.0 | 800×480 |
| CLAA090LC41CW | CPT | 9.0 | 800×480 |
| ED090NA-01H | Innolux | 9.0 | 1280×800 |
| LQ090Y3DG01 | SHARP | 9.0 | 800×480 |
| LTL090CL01-002 | Samsung | 9.0 | 1920×1280 |
| M090SWP1 R0 | IVO | 9.0 | 800×480 |
| NL8048BC24-12 | NLT | 9.0 | 800×480 |
| NL8048BC24-14NH | NLT | 9.0 | 800×480 |
| ZE090NA-01B | Innolux | 9.0 | 1280×800 |
| A070FW03 V7 | AUO | 7.0 | 480×234 |
| AT080TN42 | Innolux | 8.0 | 800×600 |
| CLAA070LFB1 CW | CPT | 7.0 | 800×480 |
| LA061WQ1-TD04 | LG Display | 6.1 | 480×272 |
| LA070WV5-SL01 | LG Display | 7.0 | 800×480 |
| LA080WV3-SD01 | LG Display | 8.0 | 800×480 |
| LQ070T5DR06 | SHARP | 7.0 | 480×240 |
| LQ080Y5DZ30A | SHARP | 8.0 | 800×480 |
| PM061WX1 | E Ink | 6.1 | 800×480 |
| TX31D16VM2BAA | KOE | 12.2 | 1024×310 |
